Low Reflection Rugged Touch Panels
Polarized & ruggedized
for outdoor harsh environments
Sunlight Readable, Rugged, and EMI Shielded Touch Panels
ALP offers both resistive and capacitive rugged touch panels. We have developed proprietary processes to integrate EMI shielding windows and heaters into both type of touch panels. In addition, we can customize and ruggedize touch panels with the following features:
​ 1. Chemically Strengthened
2. Resistant to Impact, Dust, Flame,
Water, Scratches, and Chemicals
3. Low Reflectance and
Sunlight Readable
4. High Operation Temperature
up to 80 Celsius
5. Polarized Sunglasses Compatible
with No Dark Zones
6. Integrable with EMI Windows and Heaters
PCAP touch panel integration with EMI and heater
General specifications of rugged touch panel:
We offer 4-wire, 5-wire, and 8-wire resistive touch panel options. Please check the collections out. If you don't find one in our collections, please contact us for a customized product.
4-Wire resistive touch panel selections: . .
We also offer 4-wire touch controllers for your use: .
Option 1
​
Option 2
5-Wire resistive touch panel selections:
We also offer 5-wire touch controllers for your use: .
Option 1
​
Option 2
8-Wire resistive touch panel selections: .
Suggested 8-wire touch controller for your use: .
Customization and Further Ruggedization of Rugged Touch Panels
If you do not find a touch panel that meets your requirements in our standard offerings, ALP can design a custom solution to your specifications. A sample engineering drawing of a typical customized touch panel is provided below for your reference. .
ALP offers additional ruggedization of GFG (glass–film–glass) touch panels by bonding a reinforcement glass plate to the rear of the panel:
​
1. Backing glass thickness 0.7~ 5 mm
2. Chemically strengthened glass or
regular glass may be selected
​
Total thickness of the reinforced touch panel can reach up to 9 mm and is capable of withstanding the boot kick impact test.
